MIL-DTL-83723/70B
REQUIREMENTS:
Dimensions and configurations: See figure 1.
For insert arrangement, see MIL-STD-1554.
For connector accessories, see SAE-AS85049.
This adapter is intended to be used with series III threaded coupling receptacles, including
MIL-DTL-83723/82, MIL-DTL-83723/83, MIL-DTL-83723/84, MIL-DTL-83723/85,
MIL-DTL-83723/88, MIL-DTL-83723/89 and MIL-DTL-83723/90.
This adapter shall be secured permanently to the receptacle, using a compatible thread seizing
compound.
The adapter and receptacle mate with applicable quick-disconnect plugs, including MIL-DTL-83723/66
through MIL-DTL-83723/69 (pin or socket).
Materials:
Aluminum alloy.
Qualification:
Examination of product.
Coupling torque.
Salt spray (corrosion).
Coupling torque.
Marking:
Part or Identifying Number (PIN) example:
M83723/
70
W
10
Military designator
Specification sheet number
Class
Shell size
3
