MIL-DTL-83723/71C
REQUIREMENTS:
Dimensions and configurations: See figure 1.
For insert arrangement, see MIL-STD-1554.
For connector accessories, see SAE-AS85049.
This connector mates with MIL-DTL-83723/76 and MIL-DTL-83723/78.
For insert arrangements, see MIL-STD-1554 and table I.
TABLE I. Inserts requiring reduced diameters for lead-in chamfers on contact cavities.
Shell
Insert
Contact cavities
size
arrangements
8
03
1, 2, and 3
10
06
1, 2, 3, 4, 5, 6
Marking:
Part or Identifying Number (PIN): M83723/71 X (where "X" represents the dash number from figure 1),
shell size, and the applicable code for finish.
PIN example:
M83723/
71
W
10
55
N
Military designator
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
4
