MIL-DTL-83723/74F
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ± .005 (0.13 mm) for three place decimals and
± .01 (0.25 mm) for two place decimals, and ± 1° for all angles.
4. Rear accessory interchangeability dimensions shall be in accordance with MIL-DTL-83723.
5. The centerline of indicated projection shall be located on vertical centerline ± 2°.
6. See table I for contact cavities requiring this dimension.
FIGURE 1. Dimensions and configurations - Continued.
REQUIREMENTS:
Dimensions and configuration: See figure 1.
For insert arrangements, see MIL-STD-1554 and table I.
TABLE I. Inserts requiring reduced diameters for raised seal barriers on contact cavities.
Shell
Insert
Contact
size
arrangements
cavities
8
03
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
For connector accessories: See SAE-AS85049.
This connector mates with MIL-DTL-83723/75 and /77.
O-ring shall be furnished with connector.
Part or Identifying Number (PIN) example:
M83723/
74
R
22
55
N
Military designator
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
5
