MIL-DTL-83723/77D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
For insert arrangements, see MIL-STD-1554 and table I.
TABLE I. Inserts requiring reduced diameters for lead-in chamfers on contact cavities.
Shell size
Insert arrangements
Contact cavities
8
03
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
For connector accessories: See SAE-AS85049.
This connector mates with MIL-DTL-83723/72, MIL-DTL-83723/74, MIL-DTL-83723/79,
MIL-DTL-83723/80, MIL-DTL-83723/81, MIL-DTL-83723/93 and MIL-DTL-83723/94.
Part or Identifying Number (PIN) example:
77
W
22
55
N
M83723/
Military designator
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-83723, this document references the following:
MIL-DTL-83723/72
MIL-DTL-83723/74
MIL-DTL-83723/79
MIL-DTL-83723/80
MIL-DTL-83723/81
MIL-DTL-83723/93
MIL-DTL-83723/94
MIL-STD-1554
SAE-AS85049
5
