MIL-DTL-83723/78E
REQUIREMENTS:
Dimensions and configurations: See figure 1.
For insert arrangements, see MIL-STD-1554 and table I.
TABLE I. Inserts requiring reduced diameters for raised seal barriers on contact cavities.
Shell size
Insert arrangements
Contact cavities
8
03
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
For connector accessories, see SAE-AS85049.
This connector mates with MIL-DTL-83723/71 and MIL-DTL-83723/73.
Mating force: Shall not exceed the values specified in the procurement document by more than 20
percent.
RFI spring strip shall have a minimum of six fingers per inch and shall point to rear of connector.
Part or Identifying Number (PIN) example:
M83723/
78
W
22
55
N
Military designation
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
5
