MIL-DTL-83723/82E
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 3 for classes A, G, K, M, R, T, W and Z.
See figures 2 and 3 for classes N and S.
This connector mates with MIL-DTL-83723/87, MIL-DTL-83723/92, MIL-DTL-83723/96 and
MIL-C-83723/98.
Insert arrangements and polarizing positions: See MIL-STD-1554 and table I.
TABLE I. Insert arrangements requiring reduced diameter for
lead-in chamfers on outer row of contact cavities as indicated.
Shell size
Insert arrangements
Contact cavities
8
03, 98
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
O-ring: See MIL-DTL-83723.
Part or Identifying Number (PIN) example:
M83723/
82
W
22
55
N
Military designation
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-83723, this document references the following:
MIL-C-83723/98
MIL-DTL-26500
MIL-DTL-83723/87
MIL-DTL-83723/92
MIL-DTL-83723/96
MIL-STD-1554
