MIL-DTL-83723/88E
REQUIREMENTS:
Dimensions and configurations: See figure 1.
This connector mates with MIL-DTL-83723/86, /91, /95 and /97.
Insert arrangements and polarizing positions: See MIL-STD-1554 and table I.
TABLE I. Insert arrangements requiring reduced diameters for raised seal
barriers on contact cavities as indicated.
Shell size
Insert arrangement
Contact cavities
8
03, 98
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
Connector accessories: See SAE-AS85049.
O-ring: See MIL-DTL-83723.
Part or Identifying Number (PIN) example:
M83723/88
H
22
55
N
Polarizing position
Insert arrangement
Shell size
Class
Specification sheet number
MIL number prefix
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
