MIL-DTL-83723/90F
B
C
D
E
F
Shell
A
size
Thread
UNEF-2A
8
.562-24
.394
.418
.290
.500
.562
.413
.494
10
.688-24
.515
.535
.388
.562
.696
.530
.556
12
.875-20
.685
.700
.558
.750
.875
.705
.744
14
.938-20
.754
.774
.627
.812
.936
.769
.806
16
1.062-18
.881
.901
.772
.937
1.062
.896
.931
18
1.188-18
.987
1.007
.860
1.062
1.187
1.002
1.056
22
1.438-18
1.237
1.257
1.110
1.312
1.437
1.252
1.306
X
S
Shell
G
W
size
+.005
-.000
8
.723
.400
.510
.490
.703
10
.850
.411
.572
.636
.830
12
1.055
.581
.760
.806
1.035
14
1.100
.650
.822
.875
1.080
16
1.220
.765
.947
1.002
1.200
18
1.350
.864
1.072
1.108
1.330
22
1.600
1.133
1.322
1.358
1.580
FIGURE 1. Dimensions and configurations - Continued.
