MIL-DTL-83723/96G
REQUIREMENTS:
Dimensions and configurations: See figure 1.
This connector mates with MIL-DTL-83723/82 and MIL-DTL-83723/84.
Insert arrangements and polarizing positions: See MIL-STD-1554 and table I.
TABLE I. Insert arrangements requiring reduced diameters for raised seal
barriers on contact cavities.
Shell
Insert
Contact
size
arrangements
cavities
8
03
1, 2, 3
10
06
1, 2, 3, 4, 5, 6
Connector accessories: See SAE-AS85049.
Part or Identifying Number (PIN) example:
M83723/
96
K
22
55
N
Military designation
Specification sheet number
Class
Shell size
Insert arrangement
Polarizing position
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue, due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-83723, this document references the following:
MIL-STD-1554
MIL-DTL-26500
MIL-DTL-83723/82
MIL-DTL-83723/84
SAE-AS85049
5
