MIL-DTL-83733/1D
Shell
L
M
size
3.030
2.580
A
3.000
2.570
4.330
3.880
B
4.300
3.870
Inches
mm
Inches
mm
Inches
mm
.276
7.01
1.170
29.72
3.870
98.30
.286
7.26
2.570
65.28
3.880
98.55
.558
14.17
2.580
65.53
4.300
109.22
.566
14.38
3.000
76.20
4.330
109.98
1.146
29.11
3.030
76.96
NOTES:
1.
Dimensions are in inches.
2.
See MIL-DTL-83733 for interface and backend configuration requirements.
3.
This receptacle mates with MIL-DTL-83733/4 plug.
4.
For contacts see MIL-DTL-83733 and SAE AS39029/4, SAE AS39029/50 or SAE AS39029/58.
5.
For insert arrangements see MIL-STD-1531 and MIL-STD-1532.
6.
Metric equivalents are given for information only and are based upon 1.00 inch equals 25.4 mm.
FIGURE 1. Dimensions and configurations - Continued.
