MIL-DTL-83733/10C
.
Shell
L
M
N
size
3.030
2.580
2.150
A
3.000
2.570
2.130
4.330
3.880
3.450
B
4.300
3.870
3.430
Inches
mm
Inches
mm
Inches
mm
.138
3.51
.566
14.38
3.000
76.20
.213
5.41
1.146
29.11
3.030
76.96
.223
5.66
1.170
29.72
3.870
98.30
.276
7.01
2.130
54.10
3.880
98.55
.286
7.26
2,150
54.61
4.300
109.22
.38
9.7
2.570
65.28
4.330
109.98
.558
14.17
2.580
65.53
NOTES:
1.
Dimensions are in inches.
2.
See MIL-DTL-83733 for interface and backend configuration requirements.
3.
This receptacle mates with MIL-DTL-83733/12 plug.
4.
For contacts see MIL-DTL-83733 and SAE AS39029/4, SAE AS39029/50 or SAE AS39029/58.
5.
For insert arrangements see MIL-STD-1531 and MIL-STD-1532.
6.
For fixed bushings see MS24700-2
7.
Layout arrangements containing size 22D contacts shall not be used in this shell configuration.
8.
Metric equivalents are given for information only and are based upon 1.00 inch equals 25.4 mm.
FIGURE 1. Dimensions and configurations - Continued.
