INCH-POUND
MIL-DTL-83733/12D
31 January 2011
SUPERSEDING
MIL-C-83733/12C (USAF)
28 July 1986
DETAIL SPECIFICATION SHEET
CONNECTORS, ELECTRICAL, RECEPTACLE, PIN CONTACT, MINIATURE,
RECTANGULAR TYPE, RACK TO PANEL, STAGGERED SPRING MOUNTING,
ENVIRONMENT RESISTING, 200°C
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-83733.
L
M
.566
1.170
.558
MAX.
.344
HEX
N
±.005
.223
DIA
.138-32 UNC-2B
SEE NOTE 3
.213
(4 PLACES)
.196
.036
1.250 MAX
(SPRING IN FREE
POSITION)
SEE NOTES 6 AND 7
.390
.300
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5935
