INCH-POUND
MIL-DTL-83733/4D
31 January 2011
SUPERSEDING
MIL-C-83733/4C(USAF)
31 December 1987
DETAIL SPECIFICATION SHEET
CONNECTORS, ELECTRICAL, RECEPTACLE, PIN CONTACT, MINIATURE,
RECTANGULAR TYPE, RACK TO PANEL, WITH CAPTIVE SPRINGS,
ENVIRONMENT RESISTING, 200°C
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-83733.
L
M
.566
.558
1.170
1.146
.138-32 UNC-2B
SEE NOTE 3
.196
.036
1.250 MAX
(SPRING IN FREE
POSITION)
SEE NOTES 6 AND 7
.390
.300
FIGURE 1. Dimensions and configurations.
AMSC N/A
FSC 5935
