MIL-DTL-83733/6D
Shell
L
M
size
3.030
2.580
A
3.000
2.570
4.330
3.880
B
4.300
3.870
Inches
mm
Inches
mm
Inches
mm
.005
0.13
1.146
29.11
3.870
98.30
.138
3.51
1.170
29.72
3.880
98.55
.141
3.58
2.570
65.28
4.300
109.22
.260
6.60
2.580
65.53
4.330
109.98
.558
14.17
3.000
76.20
.566
14.38
3.030
76.96
NOTES:
1.
Dimensions are in inches.
2.
See MIL-DTL-83733 for interface and backend configuration requirements.
3.
This receptacle mates with MIL-DTL-83733/1, MIL-DTL-83733/4 plug.
4.
For contacts see MIL-DTL-83733 and SAE AS39029/4, SAE AS39029/50 or SAE AS39029/58.
5.
For insert arrangements see MIL-STD-1531 and MIL-STD-1532.
6.
Metric equivalents are given for information only and are based upon 1.00 inch equals 25.4 mm.
FIGURE 1. Dimensions and configurations - Continued.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of marginal notations and relationship to the last previous issue.
