MIL-DTL-83734/1E
REQUIREMENTS:
Design and construction:
Dimensions and configurations: See figure 1 and table I.
Material and contact finish: In accordance with MIL-DTL-83734.
Termination's (see table I and MIL-DTL-83734).
a.
Type I: Solderless wrap.
b.
Type II: Printed circuit terminal.
Contact identification: See figure 1 and note 7.
Part or Identifying Number (PIN): The PIN shall consist of this specification sheet and the dash number from table I.
Example
M83734/1
010
Basic document number
Dash number (dash number from table I)
TABLE I. Dash numbers and characteristics. 1/
Termination
Dash number
Termination
Contact
Insulator
Contact
finish
M83734/1
type
style
Configuration
engagement
area finish
-010
I
A
3
Gold
Gold
-011
I
A
3
Gold
Tin/lead
-012
I
A
3
Tin/lead
Tin/lead
-025
II
A
1
Gold
Gold
-026
II
A
1
Gold
Tin/lead
-027
II
A
1
Tin/lead
Tin/lead
1/ For replacement purposes, the Government will stock, store, and issue -010, parts only.
(See MIL-DTL-83734.)
4
