MIL-DTL-83734/10G
Inches
mm
Inches
mm
5.08
.200
0.08
.003
7.62
.300
0.13
.005
7.80
.307
0.25
.010
8.10
.319
0.51
.020
12.70
.500
1.09
.043
13.97
.550
2.11
.083
15.24
.600
2.16
.085
15.59
.614
2.24
.088
16.23
.639
2.49
.098
17.78
.700
2.54
.100
24.89
.980
3.43
.135
26.67
1.050
3.81
.150
41.91
1.650
4.45
.175
48.26
1.900
4.52
.178
52.07
2.050
4.78
.188
Dash number
Dimension "A"
Dimension "B"
max/min
max
(mm)
(mm)
-010, 011, 012
.210/.190
.715
(18.20)
(5.33/4.83)
-028, 029, 030, 031, 032, 033
.175/.155
.300
(7.62)
(4.44/3.94)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.005 inch (0.13 mm) for three place.
4. A recess to be provided to fully enclose the head or nut of the fastener below the surface of the
socket.
5. Contact terminations may be round, squared, or rectangular.
6. Devices shall accept flat leads .008 inch (0.20 mm) to .015 inch (0.38 mm) thick by .015 inch (0.38
mm) to .021 inch (0.53 mm) wide. The values for mating forces are based upon the use of
standard leads .011 ±.002 inch (0.28 ±0.05 mm) thick by .018 ±.002 inch (0.46 ±0.05 mm) wide.
The length of the lead accepted by the device shall be .150 inch (3.81 mm). Contact shall be
made at or before reaching a depth of .100 inch (2.54 mm).
7. A visual polarization index shall be provided in the first quadrant. If the visual index overlaps into
the fourth quadrant, it shall be adjacent to or clockwise from contact number one.
8. It is desirable that the socket face shall be relieved to facilitate removal of the integrated circuit.
9. Ramped edges optional. Configuration of edges optional.
10. Standoffs optional for termination type I leads.
11. All dimensions of configuration 1 are applicable to configurations 2 and 3.
12. For type II terminations, there shall be a minimum of 2 standoffs. The configuration and location
of the standoffs is optional.
FIGURE 1. Dimensions and configurations - Continued.
3
