MIL-DTL-83734/3G
Supersession information: See table II.
TABLE II. Supersession information.
New PIN
Superseded PIN
M83734/3- 1/ 2/
M83734/3-
001
010
002
011
003
012
004
013
005
014
006
015
007, 016
No superseding PIN
008, 017
No superseding PIN
009, 018
No superseding PIN
1/ Dash numbers 001 through 009 are high profile sockets.
2/ Dash numbers 007 through 009 and 016 through 018
are solder cup terminations.
Replacement information: See table III.
TABLE III. Replacement information.
Replaced PIN
Replacement PIN
M83734/3- 1/
M83734/3-
013
028
014
029
015
030
028 open body frame 2/
019
029 open body frame 2/
020
030 open body frame 2/
021
031
022
032
023
033
024
028 open body frame 2/
025
029 open body frame 2/
026
030 open body frame 2/
027
1/ Replacement PINs are 2-piece contacts, style A.
2/ Dash numbers -019, -020, -021, -025, -026, -027
are solid body with type II leads.
Changes from previous issues. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
5
