MIL-DTL-9177/3C(USAF)
Inches
mm
Inches
mm
Inches
mm
.010
0.25
.203
5.16
.395
10.03
.015
0.38
.282
7.16
.401
10.19
.025
0.64
.288
7.32
.431
10.94
.045
1.14
.311
7.90
.439
11.15
.068
1.73
.312
7.92
.576
14.63
.171
4.34
.318
8.08
.802
20.37
.197
5.00
.346
8.79
.880
22.35
.350
8.89
2.440
61.98
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ± .005 (0.13 mm).
4. If the jack passes the electrical continuity test using the test plug this will be accepted as evidence
that the jack meets the contact location requirements.
5. All undimensioned pictorial representations are for reference purposes only.
6. Coin slot width .073 (1.85 mm) minimum.
7. .068 (1.73 mm) is the minimum depth measured to the theoretical intersection of the arc with the
horizontal centerline.
FIGURE 1. Dimensions and configurations Continued.
3
