MIL-PRF-39012/56G
TABLE IV. Group qualification and retention testing.
Submission and qualification of
Qualifies the following connectors
Group
any of the following connectors
3/
1/ 2/
M39012/56-*006
M39012/56-*009
M39012/56-*007
I
M39012/56-*008
M39012/56-*009
M39012/56-*010
M39012/56-*030
M39012/56B*011
II
M39012/56B*015
M39012/56B*012
M39012/56B*013
M39012/56B*014
M39012/56B*015
M39012/56B*016
M39012/56B*017
M39012/56B*018
III
M39012/56B*022
M39012/56B*019
M39012/56B*020
M39012/56B*021
M39012/56B*022
M39012/56B*023
M39012/56B*024
M39012/56-*025
IV
M39012/56-*028
M39012/56-*026
M39012/56-*027
M39012/56-*028
M39012/56-*029
V
M39012/56-*502
M39012/56-*502
1/ Individual connectors other than listed are self qualifying only.
2/ Qualification of connectors qualifies connectors of the same material only.
3/ Connectors qualified with safety wire holes automatically qualifies connectors without safety wire
holes.
* Denotes material.
NOTES:
1. For qualification retention, where more than one part is listed in a group in this column, data may
be supplied on any of those parts in order to retain qualification for those parts in the corresponding
right hand column. The part does not necessarily have to be the part initially qualified.
2. If a connector manufacturer produces a connector which meets all the requirements for two or
more connector PINs (within the same series), the manufacturer may receive qualification
approval for two or more connector PINs by qualifying the one connector. It is not
necessary that such connectors be in the same group. Each connector, however, must be marked
with its own appropriate PIN. For group qualification, the connectors must be of similar
design.
10
