MIL-PRF-39012/59G
Corona level:
Altitude: 70,000 feet (4.437 kPa).
Cable group
Volts, min.
I
125
II, IIa, III, IV
190
VI, VIa, VIb
250
RF high potential withstanding voltage:
Voltage and frequency: Tested at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable group
Volts, min.
I
335
II, IIa, III, IV
500
VI, VIa, VIb
670
Cable retention force: The cable retention force shall be in accordance with table III.
TABLE III. Cable retention force. 1/ 2/
Cable dielectric
Pounds, min. (N)
Outer diameter
Single braid
Double braid
Inches, max. (mm)
.036 (0.91)
10 (44.48)
N/A
.067 (1.70)
20 (88.96)
N/A
.110 (2.79)
30 (133.45)
N/A
.122 (3.10)
40 (177.93)
45 (200.17)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
Coupling mechanism retention force: Not applicable.
10
