MIL-PRF-39012/74D
ENGINEERING DATA:
Nominal impedance: 50 ohms.
Frequency range: 0 to 10 GHz.
Voltage rating: The voltage rating shall be as specified in table II.
TABLE II. Voltage rating.
Cables
Voltage max. (sea level)
Voltage max. 70,000 ft.
V rms
(4.437 kPa)
V rms
Cable group I
250
60
Cable group II, IIa,
335
85
Temperature rating: -65°C to +165°C.
REQUIREMENTS:
Dimensions and configuration: See figure 1 and MIL-STD-348.
Force to engage and disengage:
Longitudinal force: Not applicable.
Torque: 16 inch-ounces (.11 Nm), maximum.
Coupling proof torque: Not applicable.
Inspection conditions: Torque 35 to 50 inch-ounces (.25 to .35 Nm).
Mating characteristics: See MIL-STD-348.
Hermetic seal: Not applicable.
Leakage (pressurized connectors): Not applicable.
Insulation resistance: In accordance with MIL-STD-202, method 302, test condition B, 1,000 megohms
minimum.
Center contact retention:
Axial force: 4 pounds (17.79 N), minimum axial force. Applicable to captivated center contacts only.
Radial torque: Not applicable.
Corrosion (salt spray): In accordance with MIL-STD-202 method 101, test condition B.
5
