MIL-PRF-49142/4H
Cable retention: Not applicable.
Coupling mechanism: Not applicable.
Rise time degradation: Not applicable.
Connector durability: 500 cycles minimum at 12 cycles per minute, maximum.
Part or Identifying Number (PIN): M49142/04- (dash number from table I). CAUTION: A NICKEL
PLATED BODY COMBINATION IS AVAILABLE. THIS COMBINATION IS NOT FOR USE IN
APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A
CONCERN.
Not for Naval Air Systems Command (AS) use.
Retention of qualification: See table II.
TABLE I. Cross reference of PIN.
Superseding PIN
Dash number
("X" in the dash number allows
material options, refer to the basic
document) 1/
-X004 2/
M49142/04-0001, -0002
-X006 2/ 3/
-X104, -X106 3/
-X204, -X206 3/
Non-hermetic
-X005 2/
M49142/04-0003
-X007 2/ 3/
-X105, -X107 3/
-X205, -X207 3/
Hermetic
1/ The "X" is placed in the dash number to allow the user connector body plating
options provided in the general specification. Only connectors of the same
materials are to be intermated to reduce the possibility of dissimilar problems,
including galvanic corrosion.
2/ Preferred keying.
3/ These connectors supplied with braid termination lock washer rings.
