MIL-PRF-55339/12A
Inches
mm
Inches
mm
.760
0.56
19.30
.022
Reference
Series
Contact
.765
19.43
2.24
.088
A and B
C
Socket
.850
2.49
21.59
.098
.865
5.97
21.97
.235
.995
8.59
25.27
.338
8.66
1.005
.341
25.53
8.71
1.160
.343
29.46
8.79
1.510
.346
38.35
19.05
.750
FIGURE 1. General configuration - Continued.
DESIGN AND CONSTRUCTION
General configuration: See figure 1.
Impedance: 50 ohms, nom.
Working voltage: Sea level 1,000 V rms.
70,000 feet (4.437 kPa) 250 V rms.
Frequency range: 0 to 11 GHz.
Temperature range: -65º to +165ºC.
PERFORMANCE (installation torque is not applicable)
Dimensions: See figure 1 and MIL-STD-348.
Center contact retention: Axial force 6 lb. (26.69 N), min.
Torque Not applicable.
Force to engage and disengage: Longitudinal force 4.5 lb. (20.02 N), max.
Torque 4 in-lb. (0.45 Nm), max.
Coupling proof torque: Not applicable.
Mating characteristics:
Center contact (socket):
Oversize test pin dia. - .098 in. (2.49 mm), min.
Insertion depth - .125 in. (3.18 mm), min.
Number of insertions 1.
Max test pin (insertion force test):
Steel test pin dia. - .092 in. (2.34 mm), min.
Pin finish 16 microinches (0.41 µm).
Insertion force 2 lb. (8.89 N), max.
Number of insertions 1.
2
