MIL-PRF-55339/5A
Corona level:
Voltage: 500 V, minimum.
Altitude: 70,000 feet (4.437 kPa), minimum.
RF high potential withstanding voltage:
RF voltage: 1,500 Vrms, minimum.
Frequency: 5 MHz, minimum.
Salt spray (corrosion): Applicable.
Coupling mechanism retention force: 100 lb (444.82 Nm), minimum.
Part or Identifying Number (PIN):
M55339/05-00057 or:
M55339/05-70001 CAUTION: THIS PART HAS A NICKEL PLATED BODY AND IS NOT FOR USE
IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A
CONCERN.
TABLE I. Cross reference of PINs.
Superseded PIN or type designation 1/
PIN
M55339/05-00057
MS15507
UG-57 B/U
1/
The superseded PIN or the type designation is for cross-reference
only. Where a superseded PIN or type designation is not given, none
was assigned or will be assigned. The PIN: M55339/05-00057 shall
be used in all cases for marking and identifying the adapter.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Reference documents. In addition to MIL-PRF-55339, this document references the following:
MIL-STD-348
4
