MIL-PRF-55339/7A
RF insertion loss: .15 dB, max, 9 GHz (.050 √F (GHz) dB max tested at 9 GHz).
Durability: 500 cycles minimum at 12 cycles/min, maximum. The connector shall meet the mating
characteristics and force to engage and disengage requirements.
Dielectric withstanding: Test voltage 2,500 V rms, min (sea level).
Contact resistance (milliohms, max):
Initial
After Environmental
Contact
Center
1.5
2
Outer
0.2
N/A
Outer (-70001)
0.4
N/A
Vibration, high frequency: Interruptions 1 µs, max.
Shock: Test condition I.
Thermal shock: Test condition C.
Moisture resistance: 200 megohms, min.
Corona level: Voltage 500 V, min.
Altitude - 70,000 feet (4.437 kPa), min.
RF high potential withstanding voltage: RF voltage 1,500 V rms, min.
Frequency 5 MHz, min.
Salt spray (corrosion): Applicable.
Coupling mechanism retention force: Not applicable.
Part or Identifying Number (PIN): M55339/07-00029 or M55337/07-70001.
PIN: M55339/07-70001. CAUTION. THIS PART HAS A NICKEL PLATED BODY AND IS NOT FOR
USE IN APPLICATIONS WHERE PASSIVE INTERMODULATION GENERATION (PIM) MAY BE A
CONCERN.
Cross reference: See table I.
TABLE I. Cross reference of PIN.
PIN
Superseded PIN or type designation 1/
M55339/07-00029
MS90576
RE49D258E
UG-29C/U
1/ The superseded PIN or the type designation is for cross reference only. Where a
superseded PIN or type designation is not given, none was assigned or will be
assigned. The PIN M55339/07-00029 shall be used in all cases for marking and
identifying the adapter.
3
