INCH-POUND
MS24696A
14 July 2005 SUPERSEDING MS24696
13 October 1960
DETAIL SPECIFICATION SHEET
RETAINER, CONNECTOR, RACK AND PANEL, MINIATURE
Inactive for new design after 8 June 1999.
This specification is approved for use by all Departments and Agencies of the Department of Defense. The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-26518.
The Qualified Products List (QPL) associated with this inactive for new design specification will be maintained until acquisition of the product is no longer required, where upon the specification and QPL will be canceled.
NOTES:
1. All dimensions in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified tolerances are ±.005 inches (0.13 mm), angular tolerances are ±2°.
FIGURE 1. Spring loaded mounting assembly.
AMSC N/A FSC 5935
