MS27484N
Shell size |
K max REF |
Q dia max |
R dia +.005 -.006 |
w ±.015 |
FF max |
JJ min |
MM dia +.007 -.004 |
8 |
.155 |
.750 |
.316 |
.547 |
.036 |
.109 |
.456 |
10 |
.859 |
.436 |
.573 |
||||
12 |
1.031 |
.549 |
.733 |
||||
14 |
1.156 |
.675 |
.858 |
||||
16 |
1.281 |
.799 |
.983 |
||||
18 |
1.406 |
.893 |
1.108 |
||||
20 |
.109 |
1.531 |
1.018 |
.524 |
.017 |
.156 |
1.228 |
22 |
1.641 |
1.143 |
1.353 |
||||
24 |
1.766 |
1.268 |
.575 |
1.478 |
FIGURE 1. Plug, classes E, P and T - Continued.
2
