MS3474 Connectors, Receptacle, Electrical, Series 2, Crimp Type, Rear Mounting Jam Nut, Bayonet Coupling, Classes A, D, L, T, W And Z

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9

Shell size

A

B

F

G

H

J

8

.954 (24.23)

.923 (23.44)

1.078 (27.38)

1.047 (26.59)

.707 (17.95)

.658 (17.61)

.113 (2.87)

.086 (2.19)

.524 (13.31)

.378 (9.60)

.346 (8.79)

10

1.078 (27.38)

1.047 (26.59)

1.203 (30.56)

1.172 (29.77)

.707 (17.95)

.658 (17.61)

.113 (2.87)

.086 (2.19)

.524 (13.31)

.378 (9.60)

.346 (8.79)

12

1.266 (32.16)

1.235 (31.37)

1.391 (35.33)

1.360 (34.54)

.707 (17.95)

.658 (17.61)

.113 (2.87)

.086 (2.19)

.524 (13.31)

.378 (9.60)

.346 (8.79)

14

1.391 (35.33)

1.360 (34.54)

1.516 (38.58)

1.485 (37.72)

.707 (17.95)

.658 (17.61)

.113 (2.87)

.086 (2.19)

.524 (13.31)

.378 (9.60)

.346 (8.79)

16

1.516 (38.51)

1.485 (37.72)

1.641 (41.68)

1.610 (40.89)

.707 (17.95)

.658 (17.61)

.113 (2.87)

.086 (2.19)

.524 (13.31)

.378 (9.60)

.346 (8.79)

18

1.641 (41.68)

1.610 (40.89)

1.766 (44.86)

1.735 (44.07)

.707 (17.95)

.658 (17.61)

.113 (2.87)

.086 (2.19)

.524 (13.31)

.378 (9.60)

.346 (8.79)

20

1.828 (46.63)

1.797 (45.64)

1.954 (49.63)

1.923 (48.84)

.772 (19.61)

.721 (18.31)

.148 (3.76)

.096 (2.44)

.521 (13.23)

.378 (9.60)

.346 (8.79)

22

1.954 (49.63)

1.923 (48.84)

2.078 (52.78)

2.047 (51.99)

.772 (19.61)

.721 (18.31)

.148 (3.76)

.096 (2.44)

.521 (13.23)

.378 (9.60)

.346 (8.79)

24

2.078 (52.78)

2.047 (51.99)

2.203 (55.96)

2.172 (55.17)

.772 (19.61)

.721 (18.31)

.148 (3.76)

.096 (2.44)

.521 (13.23)

.405 (10.29)

.379 (9.63)
