W-C-596/108C
REQUIREMENTS:
Design and configuration: See figure 1.
Dimensions: Shall conform to NEMA WD 6, configuration L7-20P.
Mating face: Dead-front construction.
Armored construction: Not acceptable.
Ratings:
Voltage: 277 volts.
Current: 20 amperes.
Frequency: 50/60 hertz.
Mating connector: W-C-596/107 and W-C-596/109.
Strain relief: Accommodate cable diameter .325 - .655 inches.
Part or Identifying Number (PIN): The PIN consists of the prefix W-C, the basic specification number, the specification
sheet number, and the style number.
W-C- 596 /108 -1
Style number (see table I)
Specification sheet number
Specification number
W-C Prefix
Supersession and cross reference: See table II.
TABLE I. Dash number.
Dash no.
Supersedes style
Description
1
Straight plug
2
Angle plug
TABLE II. Supersession and cross reference. 1/
Superseded Numbers
Active
Government
CAGE
CAGE
CAGE
CAGE
CAGE
CAGE
CAGE
PIN
75582
04009
08556
71183
81091
21873
74545
6221
2331
W-C-596/108-1
L720-P
6222
2331-CY
W-C-596/108-2
1/ CAGE is the Commercial and Government Entity code which is assigned and maintained by
Defense Logistics Information Service (DLIS) in Battle Creek, MI.
2
