MIL-DTL-12883/1F
Contact resistance:
Average for all contacts: 0.015 ohm maximum.
Individual contacts: 0.03 ohm maximum.
Continuity test circuit: The header shall be the one used for electron tube 6AC7WA.
Mechanical:
Insertion and withdrawal force:
Initial insertion force: 25 pounds (111 newton) maximum.
Initial withdrawal force: 8 pounds (36 newton) minimum, 20 pounds (89 newton) maximum.
Torque: M12883/01-03 and 04 sockets shall be subjected to a torque of 12 pounds-inches
(53 newton).
Vibration: The test gage shall be in accordance with MIL-DTL-12883 (see appendix).
Durability: After the durability test, the withdrawal force shall be 5 pounds (22 newton) minimum.
Static load: 80 pounds (356 newton).
The part shall be designed to operate at the following conditions:
Environmental:
Operating temperature: See table I.
TABLE I. Dash number, and characteristics.
Dash
Operating temperature
Insulating material
Mounting style
Old type
number
ēC
designator
-01
200
Ceramic
Clearance hole
TS101C01
SDG-F, GDI-30, or
Clearance hole
TS101P01
-02
100
MFE
-03
200
Ceramic
Threaded bushing
TS101C02
SDG-F, GDI-30, or
Threaded bushing
TS101P02
-04
100
MFE
3
