MIL-DTL-12883/2E
TABLE I. Dash number and characteristics.
Dash
Operating
Insulating
Old type designator
number
temperature
and replacement
material
data 1/
ºC
-01
200
Ceramic
TS102C01 (2-way)
-02
100
SDG-F or GDI-30F
TS102P01 (1-way)
-03
100
MFE
TS102P01 (2-way)
1/ 1-way replacement: The new item (designated by military Part or Identifying Number
PIN)) will replace the old item (formerly designated by type designator);
however, the old item will not replace the new item.
2-way replacement: The two items are interchangeable; i.e., the new
item will replace the old item, and the new item will replace the new item.
Ratings (absolute maximum):
Voltage:
Sea level: 500 volts rms.
50,000 feet (15.24 km): 225 volts rms.
Current: 1 amperes.
Operating temperature: See table I.
Test gage details: See table II and MIL-DTL-12883 (see appendix).
