MIL-DTL-12883/40F
TABLE I. Dash numbers and configurations - Continued.
Contact
Number
Contact size
Mounting
designation
Dash
of
Mating relay
style
number
contacts
M39029
Mating
Wire
end
barrel
M83536/17-002, /17-005
Fixed stud
16
16
14
/92 533
20
(figure 3)
To be determined.
Fixed stud
16
16
14
/92 533
21
(figure 3)
To be determined.
Fixed stud
16
16
14
/92 533
22
(figure 3)
M83536/15-022, /16-022, /16-031,
Fixed stud
20
14
/92 534
23
16
1/ M83726/1, /2, /3, /4, /28, /29, /30, /31
(figure 3)
2/
MS27709-2
MS27745-2, -4, -5
Fixed stud
16
16
16
/92 533
24
(figure 3)
1/ Applies to all plug-in type relays of these documents.
2/ Caution: Because of the wire barrel size of -05, -11, -17, and -23, current overload may be
experienced at 10 amperes.
Environmental:
Temperature range: Operating temperature range: 70ēC to +125ēC.
Wire sealing: A resilient grommet is permanently bonded to the wire entry face of the socket so as to
provide moisture sealing capabilities (see figure 1). Wire sealing range shall be as specified in table II.
TABLE II. Wire sealing range.
Contact size
Wire sealing range
(mm)
16-20
.040 min to .083 max
(1.02 min to 2.11 max)
16-16
.065 min to .109 max
(1.65 min to 2.77 max)
Mechanical:
Vibration (sinusoidal): In accordance with MIL-STD-202, method 204, test condition G.
a. Except that the frequency range shall be varied logarithmically between the limits of 10 Hz
and 3,000 Hz.
b. Except that the procedure of method of 201 of MIL-STD-202 may be applied during 10 Hz to
55 Hz band of the vibration frequency range.
c. Qualified mating relay shall be used as a test gauge.
Vibration (random): In accordance with MIL-STD-1344, method 2005, test condition V, letter G, with
a test duration of 15 minutes. The mating relay shall be used as the test gage.
Shock (mechanical): In accordance with MIL-STD-202, method 213, condition C, except peak value
shall be 200 g's.
Insertion and withdrawal forces: The insertion and withdrawal forces of the relay and socket shall be
specified as in table III.
10
