MIL-DTL-12883/50B
Part or Identifying Number (PIN): The PIN shall consist of the basic number of this specification sheet
and the dash number from table I.
Example:
M12883/50
-001
Basic document number
Dash number (see table I)
TABLE I. Dash number and characteristics. 1/
Dash
Socket
Applicable
Color code
number 2/
configuration
relay 3 / 4/
FED-STD-595
001
I (ac)
MIL-PRF-83536/11-012
Gray 36231
002
II (dc)
MIL-PRF-83536/10-028
Black 37038
003
III (dc latch)
MIL-PRF-83536/13-010
Brown 30252
1/ Reference MIL-PRF-83536 for supersession data on MIL-PRF-6106 relays.
2/ To be used in conjunction with relay mounting track MIL-DTL-12883/49 and applicable relay.
3/ Each socket module delivered shall have a hole pattern that:
a. Permits installation of the mating relay into the socket module when the relative orientation
of the two is correct.
b. Prevents installation of this mating relay into the socket module when the relative
orientation of the two is not correct.
c. Prevents installation of all other relays into the socket module regardless of the orientation
of the socket module and the relay.
4/ Any hole molded into the socket module that results in a pattern that is not consistent with 3/ shall
be filled. The filling means shall exhibit the following characteristics:
a. If a nonmetal, the fill material shall be proved to comply with the reversion resistance and
hydrolytic stability requirements of MIL-HDBK-454, requirement 47.
b. Shall be restrained from motion relative to the module material into which it is inserted.
c. Shall have hardness comparable to that of the module material into which it is inserted.
Supersession data: See table II.
TABLE II. Supersession data. 1/
Superseded dash number
Superseding PIN
M6106/4-
001
M12883/50-001
002
M12883/50-002
003
M12883/50-003
1/ For Government logistics support, supersession data becomes
applicable when a qualified products list becomes available.
The Government PIN, specified in table III, supersedes the following commercial PINs.
4
