MIL-DTL-12883/54A
REQUIREMENTS:
Design and construction: See figure 1.
Insulator: Diallyl phthalate in accordance with ASTM D5948, type SDG-F or any glass filled
theramoplastic material in accordance with ASTM D5204.
Color: Color shall be optional providing that the color provides a contrasting background for the blue
sealing grommet/blue color bands indicating rear release contacts.
Grommet: Silicone rubber.
Mounting hardware: Corrosion resistant steel or steel with cadmium/chromate finish.
Electrical:
Contacts: Contacts shall be removable crimp type in accordance with MIL-C-39029/92 (see table I).
Insulation resistance: 1000 megohms minimum, the following conditions shall apply:
a. Test pin diameter:
Size 12, .0940 ± 0.0010 inch (2.39 ± 0.025 mm).
Size 16, .0620 ±. 0010 inch (1.575 ± 0.025 mm)
Size 20, .0400 ±. 0010 inch (1.02 ± 0.03 mm).
TABLE I. Dash numbers and configuration.
Contact size
Contact
Dash
Number of
Mating relay
Designation
Mating Wire
Number
Contacts
M39029
End
Barrel
16
16
5
/92-533
M6106/13-002, -008,
01
12
12
6
/92-535
-011, -013, -015
16
16
5
/92-533
02
M6106/13-004
12
16
6
/92/536
/92-532
2
20
20
M6106/12-002
03
/92-533
5
16
16
/92-535
6
12
12
/92-532
2
20
20
MS27742-2
04
/92-533
2
16
16
/92-535
9
12
12
Dielectric withstanding voltage:
Sea level: Test voltage, 1500 V rms.
High altitude (80,000 feet (24,384 meters)): Test voltage, 500 V rms.
Test pin diameter, size 20, .0400 ± .0010 inch (1.02 ± 0.03 mm), size 16, 0.0625 ± 0.0010 inch (1.595
± 0.025 mm), size 12, .0940 ± .0010 inch (2.39 ± 0.025 mm).
Environmental:
Temperature range: Operating temperature range -70șC to +125șC.
7
