MIL-DTL-2036E
Class 2 ­ For motors, generators, and similar rotating equipment.
Types:
Airtight
Open
Dripproof (15 degrees)
Open, protected
Dripproof (15 degrees) protected
Splashproof
Dripproof (45 degrees)
Splashproof, protected
Dripproof (45 degrees) protected
Spraytight
Dust-ignition proof
Spraytight (fan cooled)
Dustproof
Submersible (15 foot)
Dusttight
Open-submersible (15 foot)
Explosionproof
Open-submersible (50 foot)
Explosionproof (fan-cooled)
Open-submersible (1600 foot)
Submersible (50 foot)
Totally enclosed
Submersible (1600 foot)
Totally enclosed (fan-cooled)
Totally enclosed (water-air-cooled)
Watertight
1.2.1 Fan-cooled Equipment. Equipment designated as fan-cooled is described in MIL-STD-108.
Fan-cooled motors, generators, and similar equipment are listed herein because the term fan-cooled is
frequently used as a part of the enclosure designation. This specification does not contain separate
requirements for fan-cooled equipment. The requirements applicable to explosionproof, spraytight, and
totally enclosed motors, generators, and similar equipment also apply respectively to explosionproof (fan-
cooled), spraytight (fan-cooled), and totally enclosed (fan-cooled) motors, generators and similar
equipment.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification.
This section does not include documents cited in other sections of this specification or recommended for
additional information or as examples. While every effort has been made to ensure the completeness of
this list, document users are cautioned that they must meet all specified requirements of documents cited
in sections 3, 4, or 5 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks
form a part of this document to the extent specified herein. Unless otherwise specified, the issues of
these documents are those cited in the solicitation or contract.
FEDERAL SPECIFICATIONS
L-P-504
- Plastic Sheet and Film, Cellulose Acetate.
L-P-535
- Plastic Sheet (Sheeting): Plastic Strip: Poly (Vinyl Chloride) and Poly (Vinyl
Chloride-Vinyl Acetate), Rigid.
FEDERAL STANDARDS
FED-STD-H28/2 - Screw-Thread Standards for Federal Services, Section 2, Unified Inch Screw
Threads ­ UN and UNR Thread Forms.
COMMERCIAL ITEM DESCRIPTIONS
A-A-50552
- Fittings for Cable, Power, Electrical and Conduit, Metal, Flexible.
