MIL-DTL-21617B
TABLE VII. First article inspection.
Inspection
Requirement
Test
Condition
paragraph
paragraph
Group I
Visual and mechanical examination
All connectors
Insulation resistance
Mated
Withstanding voltage
Unmated
Vibration
Mated
Mechanical shock
Mated
Insertion and withdrawal force (mated connectors)
Mate/unmate
Durability
Unmated
Contact resistance
Mated
Group II
Visual and mechanical examination
All connectors
Contact retention
Unmated
Contact separation
Unmated
Insert retention
Unmated
Resistance to test prod damage (initial test) 1/
Unmated
Contact separation (socket contacts) 1/
Unmated
Resistance to test prod damage 1/
Unmated
Contact separation (socket contacts) 1/
Unmated
Moisture resistance
Unmated
Insulation resistance
Mated
Air leakage (type JS receptacle only)
Mated
Thermal shock
Mated
Group III
Visual and mechanical examination
All connectors
Salt spray (corrosion)
3.6.15
Unmated
Group IV
Visual and mechanical examination
All connectors
Solderability
Unmated
Resistance to soldering heat
Unmated
Contact retention
Unmated
1/ Size 16 socket contacts.
4.4 Conformance inspection.
4.4.1 Inspection of product for delivery. Inspection of product for delivery shall consist of groups A and
B inspections and shall be performed on a lot-by-lot basis.
4.4.2 Inspection lot. An inspection lot shall consist of all connectors of the same PIN, produced under
essentially the same conditions, and offered for inspection at one time.
