MIL-DTL-24231/1E(SH)
11
CABLE TYPE AND
LENGTH AS
1
Ø12
SPECIFIED IN THE
CONTRACT OR ORDER
10
COMPOUND,
POLYURETHANE
COMPOUND, 16
3 MIN
EPOXY
PLUG SLEEVE,
4
M24231/1-010
3
4
CONTACT SOCKET
SOFT SOLDER
TO CONDUCTORS
1
4
INSERT ASSEMBLY
9
32
12 13 14
1
COUPLING
5
M24231/1-011
KEY MUST BE LOCATED
IN POSITION SHOWN
FOUR CONDUCTOR 2
PLUG ASSEMBLY
M24231/1-002 SYMBOL NO. 713.6
KEY MUST BE LOCATED
IN POSITION SHOWN.
THREE CONDUCTOR 1
PLUG ASSEMBLY
FIVE CONDUCTOR 3
M24231/1-001 SYMBOL NO. 713
PLUG ASSEMBLY
M24231/1-003
(SAME AS M24231/1-002
EXCEPT AS SHOWN)
FIGURE 1. Connector, plug, molded, three-, four-, and five-conductor.
2
