MIL-DTL-24231/1E(SH)
TABLE I. Parts list Continued.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
When plugs are purchased as a kit, the inserts are not molded in accordance with MIL-DTL-24231/29. The
socket contacts and sleeving are individually provided.
GRE plug sleeves may be obtained from D.G. O Brien, Inc., Sea Con/Phoenix, Inc. or equal.
5/
6/
May be Ni-Al-BRZ in accordance with ASTM B150/B150M at the option of the manufacturer.
7/
Molding compound to be procured in accordance with S9320-AM-PRO-020.
8/
For cable type, see table for cross indexing of mating plugs, receptacles, adapters, and single and multiple
cable connectors of MIL-DTL-24231.
9/
To be supplied when specified (see acquisition requirements in MIL-DTL-24231).
10/
Hysol base EE4183 or RE2039, hardener HD-3561, Hysol Division, Dexter Corporation, Olean, NY, CAGE
04347, or equal.
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
