MIL-DTL-24231/10E(SH)
SAME AS M24231/10-010
EXCEPT AS SHOWN.
0.318 (TYP)
0.161 (TYP)
0.308
0.151
C
L
0.505 (TYP)
0.495
0.286
0.276
0.099
0.089
0.474
0.464
0.193
0.183
0.568
0.558
0.380
0.370
C
L
FIGURE 7. Assembly, insert, molded (40-conductor) M24231/10-035.
