MIL-DTL-24231/10E(SH)
14-COND, M24231/10-001 SYM NO. 517.2 1
24-COND, M24231/10-002 SYM NO. 517.3
2
30-COND, M24231/10-003 SYM NO. 517.6 3
40-COND, M24231/10-004 SYM NO. 517.14
4
40-COND, M24231/10-005 (FOR USE WITH
5
PART NO. M24231/4-005)
CAP, M24231/14-011 38
36 INSERT, NYLON,
GASKET, O-RING, SAE-AS28775-329 15
M24231/5-077
RING, RETAINING, M24231/10-041 29
PLATE, IDENT
18
(SEE PARTS LIST.)
GASKET, O-RING, SAE-AS28775-220 14
SCREW,
37
M24231/5-083
ASSY, INSERT, MOLDED
7
8
(SEE PARTS LIST)
9
11
10
1
GASKET, O-RING,
17
SAE-AS28775-334
ASSY, SINGLE CABLE
6
CONNECTOR BODY,
PIN,
1
35
M24231/10-040
M24231/5-071
SEE REQT. 4 & 6.
WIRE 39
19 20 21 22 23
1
51 52 53 54 55
PLATE, RETAINER (SEE PARTS LIST.)
ASSY, RETAINER PLATE
(SEE PARTS LIST.)
24 25 26 27 28
PACKING (SEE PARTS LIST.)
2
GASKET, O-RING,
16
SAE-AS28775-332
WASHER, M24231/10-043 33
2
NUT, M24231/10-042 31
RING, RETAINING,
30
NUT, GLAND,
M24231/10-045
32
M24231/10-044
SEE REQT. 3.
SLEEVING
(SEE PARTS LIST.) 12 13
1
HARDNESS READING TO BE TAKEN AT THESE POINTS.
2
HARDNESS READING TO BE TAKEN AT THIS FACE AT
120-DEGREE INTERVALS.
FIGURE 1. Connector, single cable, 14-, 24-, 30-, or 40-conductor.
3
