MIL-DTL-24231/14E(SH)
M24231/14-001, 14-COND SYM NO. 737.2
1
M24231/14-002, 24-COND SYM NO. 737.3
2
RECEPTACLE
3
M24231/14-003, 30-COND SYM NO. 737.5
ASSEMBLY
4
M24231/14-004, 40-COND SYM NO. 737.8
RING, RETAINING 16
M24231/10-041
GASKET, O-RING 14
M24231/14-011
SAE-AS28775-329
15
CAP
NYLON INSERT
10
12 PIN, CONTACT
M24231/5-077
GASKET, O-RING 13
BODY, RECEPTACLE
5
SAE-AS28775-220
M24231/14-010
PIN, GUIDE
11
M24231/12-012
ASSEMBLY, INSERT (14 COND) M24231/10-010
6
7
ASSEMBLY, INSERT (24 COND) M24231/10-020
8
ASSEMBLY, INSERT (30 COND) M24231/10-030
9
ASSEMBLY, INSERT (40 COND) M24231/10-035
FIGURE 1. Connector, multi-pin receptacle typical.
2
