MIL-DTL-24231/14E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/14- 3/
2/
no.
Description
Material/specification
Remarks
1/
001 002 003 004
1
Connector, receptacle,
1
-----
See figure 1.
14-conductor,
symbol no. 737.2
2
Connector, receptacle,
1
-----
See figure 1.
24-conductor,
symbol no. 737.3
3
Connector, receptacle,
1
-----
See figure 1.
30-conductor,
symbol no. 737.5
4
Connector, receptacle,
1
-----
See figure 1.
40-conductor,
symbol no. 737.8
5
Body, receptacle
1
1
1
1
Ni-Cu, Class A,
See figure 2.
QQ-N-281
6
Insert assembly, molded
1
M24231/10-010
See figure 1.
7
Insert assembly, molded
1
M24231/10-020
See figure 1.
8
Insert assembly, molded
1
M24231/10-030
See figure 1.
9
Insert assembly, molded
1
M24231/10-035
See figure 1.
10
Insert
1
1
1
1
M24231/5-077
See figure 1.
11
Pin, guide
1
1
1
1
M24231/12-012
See figure 2.
12
Pin, contact
14
24
30
40 MIL-DTL-24231
Integral to molded insert
assemblies 6, 7, 8, and 9;
see figure 1.
4/
13
Gasket, O-ring
1
1
1
1
SAE-AS28775-220
Lubricate with silicone
compound SAE-AS8660;
see figure 1.
4/
14
Gasket, O-ring
1
1
1
1
SAE-AS28775-329
Same as item 13.
15
Cap, pressure-proof
1
1
1
1
Ni-Al-BRZ,
See figure 3.
5/
ASTM B150/B150M
16
Ring, retaining
1
1
1
1
M24231/10-041
See figure 1.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo
Drive, Lexington, KY 40509, CAGE 02697, or equal.
5/
May be high impact plastic, PVC, commercial when pressure-proof cap is not specified (see requirement for
pressure-proof caps in MIL-DTL-24231).
5
