MIL-DTL-24231/15E(SH)
1
3 COND, M24231/15-001 SYM. 1115
ADAPTER ASSEMBLY
4 COND, M24231/15-002 2
CHAIN, SAFETY, - 5" LONG
7
M24231/15-042
SCREW, RH 0.164-32NC-2A
SCREW, RH 0.164-32NC-2A
18
8
X 3 LG, M24231/15-043
X 12 LG, M24231/15-041
8
NYLON INSERT Ø0.125
15
X 0.203 LG (2 REQD)
ASSEMBLY, CAP
9
M24231/15-040
ASSY, INSERT MOLDED
4
M24231/15-020 OR
5
M24231/15-030
MONEL PIN Ø0.083
11
LENGTH TO SUIT
1
FLANGE 14 IN.
6
HIGH IMPACT PVC
GASKET, O-RING
12
M24231/15-040
SAE-AS28775-115
DRILL Ø0.094 HOLE AT
ASSY ADPTR BODY
3
ASSY FOR SPRINGPIN
M24231/15-010
RETAINING RING,
14
SPRINGPIN, CRES
17
M24231/5-073
NASM171502
GASKET, O-RING (2
13
REQD) SAE-AS28775-215
CAP, M24231/12-011 19
1
Ø32
MOUNTING DIMENSIONS
1
MOUNTING BOLTS 2-13
FIGURE 1. Connector, adapter typical.
