MIL-DTL-24231/15E(SH)
C
L
0.156
0.077
0.055R
0.135
MOLD IN PIN
NUMBERS ON
EACH END.
Ø0.860
Ø0.610
0.600
13
PIN, CONTACT
32
16
(6 REQD)
0.187
INSERT
SOLDER
3
21 WIRE
8
2.000
9
64
MOLDED EPOXY
20
1
64R
RESIN
0.053
7
16
Ø0.625
EACH PIN SHALL BE
Ø0.714
CONNECTED TO ITS
0.710
MATCHING PIN NO.
ON OPPOSITE END.
0.135
0.077
0.156
C
L
FIGURE 6. Assembly, insert, molded M24231/15-020 (3-conductor).
4
6
