MIL-DTL-24231/16E(SH)
ASSEMBLY, ADAPTER (7-COND)
1
M24231/16-001 SYM. NO. 1116
SAFETY CHAIN
BRASS SCREW M24231/15-043 10
13
M24231/15-042
ASSEMBLY, CAP
17
M24231/16-030
SPRING PIN
14
CRES NASM171502
PIN, GUIDE
9
BRASS SCREW
11
M24231/15-041
1
FLANGE, 12" HIGH
12
IMPACT RIGID PVC
DRILL 0.094 HOLE
M24231/16-040
AT ASSEMBLY
FOR SPRING PIN
ASSEMBLY INSERT,
ASSY, ADAPTER BODY
3
2
MOLDED M24231/16-020
M24231/16-040
Ø 0.127
NYLON INSERT
GASKET, O-RING
0.123
4
7
X 0.203 LG (2 REQD)
SAE-AS28775-213
M24231/5-077
6 CAP, M24231/13-011
RETAINING RING
15
M24231/7-041
GASKET, O-RING (2 REQD)
8
SAE-AS28775-220
Ø37
8
MOUNTING DIMENSIONS
1
MOUNTING BOLTS 2-13NC-2A
FIGURE 1. Connector, adapter.
2
