MIL-DTL-24231/16E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/16- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
1
Connector, adapter,
1
------
See figure 1.
7-conductor, symbol no. 1116
2
Body, adapter
1
Ni-Cu, Class A, QQ-N-281
See figure 2 and
requirement 2.
3
Insert assembly, molded
1
See items 16, 17, and 19.
See figure 5.
4
Insert
2
M24231/5-077
See figure 1.
5
Pad, ½ diameter by ¼
1
Ni-Al-BRZ,
See figure 4.
ASTM B150/B150M
4/
6
Cap, pressure-proof
1
M24231/13-011
See figure 1.
5/
7
Gasket, O-ring
1
SAE-AS28775-213
Lubricate with silicone
compound,
SAE-AS8660; see
5/
8
Gasket, O-ring
2
SAE-AS28775-220
See item 7.
9
Pin, guide
4
M24231/12-012
See figure 1.
10
Screw, roundhead
1
M24231/15-043
See figure 1.
11
Screw, roundhead
1
M24231/15-041
See figure 1.
12
Flange, 1½-inch
1
High impact rigid PVC
See figure 3.
6/
13
Chain, safety
1
M24231/15-042
See figure 1.
14
Pin, spring
1
CRES, NASM 171502
See figure 1.
15
Ring, retaining
1
M24231/7-041
See figure 1.
16
Pin, contact
14
MIL-DTL-24231
See figure 5.
17
Cap, assembly
1
M24231/13-011, modified as
See figure 4.
shown 4/
7/
18
Epoxy resin, molded
As required
Cast epoxy resin compound
See figure 5.
19
Wire
As required
Type B-16, SAE-AS22759/11
See figure 5.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Cap material shall be Ni-Al-BRZ, ASTM B150/B150M.
5/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo
Drive, Lexington, KY 40509, CAGE 02697, or equal.
6/
Safety chains shall be coated with gray plastisol or covered with sleeving in accordance with MIL-I-631
(size number 1, 0.294 id, Subform Ua, Grade a, Class II, Category 1, color white) for noise reduction.
7/
Arco Set 200, M.M. Reif and Co., Ivyland, PA, or PR610-TCF (Chockfast Orange), ITW Philadelphia Resins
Corp., Montgomeryville, PA, or equal.
