MIL-DTL-24231/21E(SH)
PLUG ASSEMBLY M24231/21-001
SYM. NO. 1118
Ø23
4
CABLE 10
COMPOUND,
POLYURETHANE
3
(MIN)
2
17
8
45°
ASSEMBLY, PLUG
2
SHELL, M24231/21-010
COMPOUND,
SOLDER
15
EPOXY
8
SEALING WAX
1
COUPLING,
6
AL-BRZ
SET SCREW 4-20UNC-15 LG.
1
6
M24231/21-030
7
CRES HDLS, SOC-HD, FULL DOG PT
GASKET, O-RING
BALL BEARING,
5
SAE-AS28775-230
4
Ø13 (42 REQD)
6
ASSEMBLY, SOCKET
3
INSERT, M24231/21-020
PIN, GUIDE 14
FIGURE 1. Connector, plug, 80-conductor.
2
