MIL-DTL-24231/21E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/21- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
1
Plug, 80-conductor,
1
------
See figure 1.
symbol no. 1118
2
Shell, plug
1
Ni-Cu-Al, QQ-N-286
3
Insert assembly, plug
1
See items 09, 11, and 12.
Bearing, ball 3/16 diameter
4
42
Bronze, ASTM F2215
See figure 1.
4/
5
Gasket, O-ring
1
SAE-AS28775-230
Lubricate with silicone
compound, SAE-AS8660;
see figure 1.
6
Coupling
1
Ni-Al-BRZ,
See figure 4.
ASTM B150/B150M
7
Screw, set, ¼-20UNC by
1
CRES, coml
See figure 1.
/16 Lg, HDLS-Soc-Hd, full
5
dog point
8
Wax, sealing
As required
Coml
See figure 1.
5/
9
Compound, polyurethane
As required
10
Cable, Type ECM
As required
MIL-DTL-24643/38
See figure 1.
11
Contact, socket
80
MIL-DTL-24231
See figure 2, section A-A.
12
Sleeving, socket no. 9,
As required
Type F, Subform Ua, Grade a,
See figure 2, section A-A.
0.118 id by 9/16 long
Class II, Category 1, color
clear, MIL-I-631
13
Pin, polarizing,
1
Ni-Cu, Class A, QQ-N-281
See figure 3.
0.156 diameter
14
Pin, polarizing,
1
Ni-Cu, Class A, QQ-N-281
See figure 3.
0.156 diameter, length to
suit
6/
15
Compound, epoxy resin
As required
Cast epoxy resin compound
Base EE4183 or RE2039,
hardener HD-3561;
see figure 1.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo
Drive, Lexington, KY 40509, CAGE 02697, or equal.
5/
Molding compound to be procured in accordance with S9320-AM-PRO-020.
6/
Hysol base EE4183 or RE2039, hardener HD-3561, Hysol Division, Dexter Corporation, Olean, NY,
CAGE 04347, or equal.
