MIL-DTL-24231/24E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/24- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
1
Connector, single cable,
1
Same as M24231/9-001; except
See figure 1.
symbol no. 517.13
as shown.
2
Insert, assembly, molded
1
See items 04, 05, and 06.
See figure 2.
3
Plate, identification
1
CRES or Al, MIL-DTL-15024
See figure 3.
4
Pin, contact
3
MIL-DTL-24231
See figure 2 and
requirement 2.
5
Cable, LSTHOF-9
As required
MIL-DTL-24643/3
4/
6
Epoxy resin, molded
As required
Cast epoxy resin compound
See figure 3.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Arco Set 200, M.M. Reif and Co., Ivyland, PA, or PR610-TCF (Chockfast Orange), ITW Philadelphia Resins
Corp., Montgomeryville, PA, or equal.
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
