MIL-DTL-24231/8E(SH)
TABLE I. Parts list Continued.
Quantity for
Item
M24231/8- 3/
Description 2/
Material/Specification
Remarks
no. 1/
001
002
003
30
Insert assembly, molded
1
1
1
See items 05, 26 and 27, 28, or
See figure 4.
29
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Arco Set 200, M.M. Reif and Co., Ivyland, PA, or PR610-TCF (Chockfast Orange), ITW Philadelphia Resins
Corp., Montgomeryville, PA, or equal.
5/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo
Drive, Lexington, KY 40509, CAGE 02697, or equal.
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
Preparing activity:
Navy SH
(Project 5935-2011-057)
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil.
